Why Proper Air Ventilation is More Important Than Ever

If you’re planning a re-roofing project, we recommend in-depth consideration of the building ventilation under the roof. Inadequate attic venting can cause ice dams, energy loss, and moisture damage to the roof structure. Too often roof re-surface projects repeat the mistakes of the past.

A proper roof project includes a review of the capacity of the soffit and ridge vents based on new codes, reducing penetrations through the internal vapor barrier, and increasing the attic floor insulation to meet today’s energy standards. This review is best performed by an engineer familiar with appropriate building science.

Seasonal Considerations

All buildings need to vent and most people think venting is a summer issue. It’s true that an attic only needs one tenth the ventilation in the winter than in the summer to control moisture buildup and temperature. However, the winter time also has some unique issues.

First and most important, cold weather brings ice dams and heat loss due to poor insulation which are both directly related to ventilation problems. Second, if repairs are needed, it is better to plan in the winter so that your bid documents are ready for the spring and summer construction season. And third, an attic inspection is much more pleasant during the colder temps than on an August afternoon!

Building Ventilation Best Practices

There are a lot of myths about what makes good ventilation in an attic. It is not true that rising hot air venting through ridge or gable vents is the best natural ventilation. This is sometimes called gravity ventilation. Tests have shown this chimney effect is negligible when compared to wind movement which has a much higher efficiency and allows for considerably smaller net venting area to be successful.

The difficulty with relying on wind movement is that areas of high and low pressure will change with wind direction. Thus, existing buildings are dependent on the design of the building and its orientation for determining the type and location of vents. The best designs have the outlet as high as possible (such as a ridge vent) and the inlet as low as possible (such as the soffit area). To improve this air flow, air chutes are often installed during initial construction or later retrofitted. These chutes are formed plastic channels that are attached to the roof joists and are butted up to the soffit vents to act as a pathway conduit for air coming through the soffit vents. They also serve as a barrier to prevent the attic insulation from clogging the soffit vents.

Soffit vents are probably the most important of all vents as they can act as both an inlet and outlet for air flow. That is why it is imperative they be kept free of debris or other material that could clog the vents. Without soffit venting, the ridge or high gable vents would draw make-up air through the ceiling instead of from outside. For this reason, the soffit vent should have at least 50 percent of the vent free area (NFA). This NFA rating is stamped on vent products. A rule of thumb is that the summer ventilation requirement can be estimated by determining the volume of attic space and dividing by 2 which will produce the needed cubic feet per minute (cfm) of ventilation.

When selecting replacement vents always seek vents that will have low air flow resistance. They come in either perforated or slotted. Some ridge vents come with baffles which are designed to draw air out due to the suction developed.

As we discussed, venting needs in the winter are often different than the summer. Winter ventilation is needed to remove attic moisture arising from the living space. It has been found that a great deal of moisture from as low as wet basements and crawlspaces can travel through the house’s floor penetrations. This moist air can then cool its water vapor and condense onto roof sheathing. A well ventilated attic will produce a more uniform temperature across the roof sheathing, thus minimizing warm spots near the eaves that create ice dams from cyclical refreezing of snow or rain on the roof.

In summer, of course, the main problem from poor attic ventilation is heat. Ninety degree weather can create temperatures of over 150 degrees in an attic. Heat can kill your air conditioning budget and reduce the lifespan of an asphalt shingle roof by one half its rated life.

For more information on building ventilation and how we can help you, call us today! 802-747-4535
